5 August 2025
By David McGregor, Security Standards Manager, AusPayNet
AS2805 is the Australian standard for electronic funds transfers used primarily for card-based payment transactions. It defines the structure and contents of messages, describes details of the cryptography used to secure payments and the protocols used to ensure interoperability between terminals, acquirers, issuers and card networks.
The AS2805 standard was first published in 1985. Initially Parts 1-5 were published, with further parts added in subsequent updates. These standards exclusively used Data Encryption Standard (DES) with a 56-bit key for protection of PINs and message authentication using a Message Authentication Code (MAC). Triple Data Encryption Standard (TDES) was added as an approved encryption algorithm in 2000 (as defined in AS2805.5.4) and incorporated into other parts of AS2805 over time.
Card payments in Australia continue to use cryptography based on TDES, even though stronger and faster cryptography is now available. There is a need to upgrade systems and move them away from known vulnerable algorithms, such as TDES, to known stronger algorithms including Advanced Encryption Standard (AES).
Many parts of AS2805 assume TDES and have not been updated despite advances in general cryptography and payments security. Standards produced by global bodies have benefited from regular updates from various stakeholders with support for AES, Elliptic Curve Cryptography (ECC), key blocks and other modern security features.
As a component of this modernisation effort, the suite of AS2805 standards has been revisited to determine if existing standards are still relevant, require updates or should be withdrawn. IT-005 is the working group responsible for AS2805 standards and has been making these changes with support from Standards Australia.
As a result of this review, several parts from AS2805 have been withdrawn or replaced where appropriate by an equivalent ISO standard. AusPayNet and its members prefer the use of such international standards over Australian specific standards.
Superseded AS2805 Part | Replacement ISO standard |
---|---|
AS 2805.6.1.1-2009 AS 2805.6.1.2-2009 AS 2805.6.1.4-2009 |
AS ISO 11568:2025 / ISO 11568:2023 |
AS 2805.16-2008 | AS ISO 18245:2025 / ISO 18245:2023 |
AS 2805.12.x-2008 (all parts) | AS ISO 8583:2025 / ISO 8583:2023 |
AS 2805.13.1:2000 | AS ISO/IEC 10118.1:2016/Amd 1:2021 |
AS 2805.5.1:1992 | None – No more Single DES |
The review also found that a relevant ISO standard wasn’t available for three other parts from AS2805 and IT-005 has decided to revise these parts:
All three of these updated documents are currently open for public comment at https://comment.standards.org.au/. Parts 9 and 6.9 close for comments on Thursday, 28 August 2025, with Part 2 closing on Wednesday, 10 September.
Interested readers are encouraged to review the draft and submit feedback before the comment period ends.
